About Instructor
Course Overview
Steel structures represent a major portion of the construction industry. We provide an integrated diploma in designing of steel structure buildings for civil engineers starting from geometry by CAD to analysis & design then connections and finally linking all these to final drawings with minimal external interference. It focuses on American Codes (AISC, ASCE and IBC) with an overview on the Egyptian Code. It also include using of Bentley STAAD Pro & RAM Connections. Brought to you
Course summary
CURRICULUM
1.Introduction to steel design and layout arrangement
2.Calculation of Gravity loads, Wind and Seismic loads as per different codes of practice and projects design criteria.
3.Design of Tension and Compression members.
4.Design of members subject to Combined Axial, Shear and bending forces
5.Design of Composite sections + crane girders and sections subject to torsion forces.
6.Design of base plates, anchor bolts and shear lugs.
7.Bentley STAAD.Pro. V8i analysis & Design
8.STAAD.Pro Materials and specifications assignments.
10.Applying loading and loading combinations to STAAD.Pro.
11.Post processing and reading results.
9.Wind and Seismic loading calculations using IBC-03 and ASCE7-02.
12.Design of steel and concrete sections, issuing complete calculation sheet and MTO
13.Connections Design
14.Moment connections + Bracing connections
- Design_Guide_4_Extended End-Plate Moment Connections Seismic and Wind Applications (Second Edition)
- Design_Guide_13_Wide-Flange Column Stiffening at Moment Connections.
15.Columns and beams splices + Design of stiffeners.
